Product Description
NVU kits for 70-81 Pontiac Firebird update the look of your dash to match the theme of your ride Plus offer updated, modern internals and functions you expect in today's builds. All kits include NVU's exclusive laminate mounting system that installs in the factory mounting holes without cutting up your dash plate. Functional turn signals can be displayed in the factory panel with the included LEDs. We even added a separate LED to light up your wiper switch, just like original! Kits include Speedo, Tach, fuel (factory match 0-90 Ω) , water temp, oil pressure and internally displayed voltmeter (on OLED Screen). Bushings, brackets, temperature sender, pressure sender, AMP harnesses and programming buttons also included in the kit.
Performance Series instruments Update the look of your dash with a race-inspired performance look without the "in your face" look of a racing gauge. Clean, bold graphics, flat glass lenses, incandescent perimeter lighting and modern pointers bring a performance appearance to the dash with some class. A great look for updating without going overboard in restomods, protouring or any other build that wants that upgraded look. Performance series speedometers and tachometers Feature all of NVU's Phoenix platform technology with OLED screens, performance timers, shift alert and multiple additional inputs. Minor gauges feature short sweep movements for that easy to read look you want when monitoring the vitals.
More on our phoenix platform can be found HERE>
Included in the kit:
Gen II (70-81) Firebird mounting bracket kit
Speedometer 4-3/8" 140 MPH with Phoenix features and one additional analog input
Tachometer 4-3/8" 8,000 RPM with Phoenix features and 2 additional inputs
2-1/16" Fuel gauge 0-90 Ω (GM factory match)
2-1/16" Voltmeter 10-16V
2-1/16" Oil pressure 0-100 PSI
2-1/16" Water temp 140-280 F
Back-clamps
Incandescent bulbs
2 ea AMP connectors
Water temperature sender Hi Match
Oil pressure sender 240-33Ω 1/8-27 NPT
Bushing kit 1/8-27 NPT to 1/4", 3/8", 1/2"
*SPEED SENDER MAY BE REQUIRED CHECK YOUR APPLICATION
